BMW ZB Top Rear Side View Camera Control Module TRSVC/ICAM2
BMW ZB Top Rear Side view Camera (TRSVC, also known as ICAM2) is an OEM-grade multi-camera system core module for BMW Group vehicles. It integrates front, rear, and dual side mirror cameras to generate 360° surround, top-down, rear, and side views via Ethernet/APIX data transmission, enabling precise parking and low-speed maneuvering assistance.
Core Functions
- 360° Surround View: Stitch front/rear/side camera feeds into a bird’s eye panoramic view.
- Top View: Overhead perspective for tight space parking and obstacle detection.
- Rear View: High-resolution reverse camera with dynamic steering-linked guidance lines.
- Side View: Left/right curb/obstacle monitoring (rear to front perspective).
- 3D View & Movable Perspective: Interactive 3D rendering with user-selectable angles via iDrive.
- Cross Traffic Alert: Front/rear cross traffic warning for junction/driveway exits.
- Obstacle & Curb Warning: Visual alerts for nearby objects and curbs.
- Automatic View Switching: Contextual view selection based on gear/steering/speed.
- Night Vision: Low-light performance for 24/7 usability.
Compatible Software & Systems
- iDrive 4/5/6/7/8: Native integration with BMW’s central infotainment.
- ISTA D / ISTA P: Dealer-level coding, programming, and calibration.
- E SYS: OEM coding for feature activation and camera calibration.
- ICAM2 / TRSVC Control Unit Software: Core firmware for image processing.
- Park Distance Control (PDC): Synergistic operation with ultrasonic sensors.
Supported Vehicle List
- BMW Passenger Cars (2010+)
- F Series: F20/F21 (1 Series), F22/F23 (2 Series), F30/F31/F34 (3 Series), F32/F33/F36 (4 Series), F10/F11/F07 (5 Series), F06/F12/F13 (6 Series), F01/F02 (7 Series), F25/F26 (X3/X4), F15/F16 (X5/X6), F45/F46 (2 Series Active Tourer)
- G Series: G20/G21 (3 Series), G30/G31 (5 Series), G11/G12 (7 Series), G01/G02 (X3/X4), G05/G06/G07 (X5/X6/X7), G29 (Z4)
- I Series: i3 (I01), i8 (I12/I15), i4 (G26), iX (I20)
- BMW Group
- MINI: F54–F60 (Cooper/Clubman/Countryman)
- Rolls-Royce: Post 2010 models (Wraith, Dawn, Cullinan, Ghost)
